| Low Profile Tank | Utility Tank with Slosh Guard |
Flat Bottom Utility tanks can be used for many applications. These tanks are commonly installed in trucks or trailers for lawn care, pest control, construction, trades, mobile washing, motorsports and outdoor recreation. Select sizes have bands available as shown below. The tanks may be used with or without bands.
A newly designed fillwell (slosh guard in description below) helps ensure user safety and helps avoid the spillage often seen in mobile applications. The redesigned ribs make strapping tanks down easy and secure.
| Flat Bottom Utility Tanks | |||||||
| Gallon Capacity | Width | Overall Height | Length | Fill Opening | Outlet/Drain Specification | Premium Weight Part No. White | Avail |
|---|---|---|---|---|---|---|---|
| 7¤ | 9" | 18" | 14" | 5"-(63484) | NA | 44852 | I |
| 16¤ | 14" | 17" | 20" | 5"-(63484) | NA | 44853 | I |
| 20¤ | 11" | 34" | 15" | 5"-(63484) | NA | 44854 | I |
| 25¤ Rectangular | 14" | 12" | 34" | 5"-(63484) | 3/4"-(60401) | 45879 | T |
| 26¤ | 18" | 20" | 25" | 8"-(63480) | 3/4"-(60401) | 43835 | B,C,D,E,I,L,T |
| 35¤ | 15" | 43" | 15" | 5"-(63484) | 1"-(60427) | 44873 | I |
| 45¤¬ | 18" | 22" | 38" | 5"-(63484) | 1"-(60427) | 43837 | B,C,D,E,I,L,T |
| 50 w/slosh guard | 19" | 21-1/2" | 38" | 8"-(63480) | 1"-(60427) | 43292 | B,C,D,E,G,I,L,T |
| 50 Rectangular | 26" | 15" | 41" | 7"-(63571) | 1"-(60427) | 45880 | T |
| 50 | 19" | 23" | 38" | 8"-(63480) | 1"-(60427) | 42341 | B,C,D,E,I,L,T |
| 52 | 24" | 15" | 43" | 5" Hinged-(63673) | 1"-(60427) | 43839 | B,C,D,E,I,L,T |
| 55¬ | 18" | 44" | 18" | 5"-(63484) | 1"-(60427) | 44855 | I |
| 68 | 27" | 17" | 42" | 5" Hinged-(63673) | 1"-(60427) | 43841 | B,C,D,E,I,L,T |
| 100 Rectangular | 26" | 28" | 41" | 7"-(63571) | 1"-(60427) | 45881 | T |
| 100 w/slosh guard | 26-3/4" | 27-3/4" | 42-1/2" | 8"-(63480) | 1"-(60427) | 43294 | B,C,D,E,G,I,L,T |
| 100 | 27" | 29" | 43" | 8"-(63480) | 1"-(60427) | 42343 | B,C,D,E,I,L,T |
| 110 Low Profile | 35" | 18" | 48" | 5" Hinged-(63673) | 1"-(60427) | 42349 | B,C,D,E,I,L,T |
| 150 w/slosh guard | 36" | 28-3/8" | 48" | 8"-(63480) | 1"-(60427) | 43296 | B,C,D,E,G,I,L,T |
| 150 | 36" | 29" | 48" | 8"-(63480) | 1"-(60427) | 42345 | B,C,D,E,I,L,T |
| 200 | 36" | 36" | 48" | 8"-(63480) | 1"-(60427) | 42347 | B,C,D,E,I,L,T |
| 200 w/slosh guard | 36" | 36-3/4" | 48" | 8"-(63480) | 2"-(63481) | 43298 | B,C,D,E,G,I,L,T |
| 200 Low Profile | 48" | 20" | 60" | 8"-(63480) | N/A | 44875 | E,I |
| 250 Rectangular | 48" | 19" | 68" | None | N/A | 42492 | T |
| 300 Low Profile | 56" | 19" | 95" | 8"-(63480) | N/A | 44233 | C,T |
| 500 Low Profile | 52" | 23" | 130" | 8"-(63480) | N/A | 44643 | B,T |
| 1000 Low Profile | 90" | 21" | 134" | 8"-(63480) | N/A | 45735 | B,T |
| NOTE: The 7 gallon is packaged 4 per box. No single piece shipments. ¤May ship UPS ¬Fitting is loose, not installed. |
|||||||
Availability Key: A=All; B=St.Bonifacius, MN; C=Lancaster, OH; D=Griffin, GA; E=Shawnee, OK; F=Tooele, UT; G=Owego, NY; H=Washougal, WA; I=Sheldon, IA; L=Hanford, CA; T=Fairfield, TX
Norwesco bands are custom fabricated to support the Norwesco tanks and are galvanized for added corrosion protection. Whether using the tank in a stationary position or for transport, bands are necessary to ensure that the tank retains its shape and integrity.
| Flat Bottom Utility Tank Bands | ||||||
| Tank Size/Part # | A | B | C | Color of band foot | No. of Bands | Part No. |
|---|---|---|---|---|---|---|
| 50¤ 42341 | 19" | 18 1/2" | 23" | Galvanized 1" EMT | 2 optional | 63551 |
| 100¤ 42343 | 24" | 25" | 29 1/2" | Galvanized 1" EMT | 2 optional | 63552 |
| 150¤ 42345 | 24" | 34 1/2" | 39" | Galvanized 1" EMT | 2 optional | 63553 |
| 200¤ 42347 | 33" | 34 1/2" | 39" | Galvanized 1" EMT | 2 optional | 63554 |
| ¤May ship UPS EMT=Electrical Metallic Tubing |
||||||
Tank dimensions and capacities may vary slightly and are subject to change without notice.
